Instrument features
- Using gold plated 3.5mm connector, cost-effective
- Low power waste and long standby time
- Adapt to a variety of impact devices and 6 kinds of hardness standard conversion
- Big and clear digital display
Main Technical Parameters
| Function |
Parameter |
| Measuring Range |
170-960HLD |
| Hardness Standard |
HL, HRC, HRB, HV, HB, HS |
| Error |
Indication Error ≤±6HLD（When HLD=760±30）;Repeatability ≤6HLD（When HLD=760±30） |
| Measuring Direction |
360° (down, inclines down, level, inclined up and up) |
| Screen Display |
128*64 dot matrix LCD, backlight and adjustable contrast |
| Data Memory |
:100 group of readings |
| Measurable Material |
Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, nodular cast iron, aluminum casting alloy, copper zinc alloy(brass), copper tin alloy(bronze), fine copper |
| Power |
3*1.5V AAA |
| Weight |
0.22Kg (Standard Configuration：Host + D Impact device) |
| Dimension |
155mm×68mm×27mm |
| Standard Configuration |
Host, D Impact device, Standardized blocks, Charger, Little support ring, nylon cleaning brush |
